| Features
An audio monitor provides a signal with variable pitch and amplitude, allowing you to hear changes in blood pressure. Digital LCD display provides average or peak signal values from 0 to 1999 mV. With an optional pressure gauge (not provided — see PM015D/R), the user may calibrate the display to read mm Hg. Recorder output connector allows direct connection to a pen recorder, oscilloscope or computer via a data acquisition system. BP1 accepts WPI’s BLPR blood pressure transducer as well as other blood pressure transducers.
Specifications
| Amplification |
x1, x10, x100, variable (x5-x1000) |
| Bandwidth, small signal (-3dB) |
300kHz (x1)
30kHz (x10)
3kHz (x100)
0.3kHz (x1000) |
| Output voltage swing |
±5V |
| Maximum output current |
2mA |
| Input impedance, each input |
100kΩ || 0.01μF |
| Transducer applied volts |
10V nominal, varies with load; 25mA, maximum |
Digital panel meter
|
0-1999mV (calibrated in mmHg pressure when supplied with pressure guage) Meter reads average value or ± peak (1-20Hz) |
| Power |
95-135V or 220-240V, 50/60Hz |
| Dimensions |
8.5x5.12x10" (21.6x13x25.44cm) |
| Shipping weight |
11 lb. (5kg) |
|
